Page 14 - Buffers USA 2018 Lashing Catalog
P. 14

D-RINGS w/ STRAPS
                                ®




                                            A     C                                    STANDARD-TYPE D-RINGS
                                                                                    NOTE: D-Ring strength for tie-down
                                                                                    purposes only. NOT FOR LIFTING.
                                                    B
              FINISH:
     2902     SC – SELF-COLOR                            G      E
              HDG – HOT-DIP GALVANIZED
              PR – PRIMER                   D               F
                                                                   D-RING DIMENSIONS       STRAP DIMENSIONS
                  MODEL      DESC.  FINISH WEIGHT  SWL    MBS      A       B      C      D      E      F    G
                                         0.25 LBS
              2902-6367-1-SC  D-RING  SC
                                         0.28 Kg  3,333 LBS  10,000 LBS  2-7/16"  2-7/16"  3/8"  1-1/2"  3/4"  1-1/2"  1/4"
                                         0.20 LBS  1,512 Kg  4,536 Kg   62.4 MM 62.6 MM  10 MM  38 MM  19 MM  38 MM  6 MM
              2902-6367-2-SC  STRAP  SC
                                         0.09 Kg
                                         1.30 LBS
              2902-7576-1-SC  D-RING  SC
                                         0.59 Kg  6,333 LBS 19,000 LBS  4-1/4"  4-1/4"  5/8"  2-1/2"  1-3/16"  1-3/4"  3/8"
                                         0.75 LBS  2,873 Kg  8,618 Kg  108.2 MM 108.2 MM  16 MM  63.5 MM  30 MM  44.5 MM 9 MM
              2902-7576-2-SC  STRAP  SC
                                         0.34 Kg
                                         1.64 LBS
              2902-6490-1-PR  D-RING  PR  0.74 Kg  9,000 LBS 27,000 LBS  4-1/2"  4-1/2"  3/4"  2-11/16"  1-5/16"  1-7/8"  3/8"
                                         0.94 LBS  4,082 Kg  12,247 Kg  114.2 MM 114.2 MM  19 MM  68 MM  34 MM  47 MM  9 MM
              2902-6490-2-PR  STRAP  PR
                                         0.43 Kg
                                        1.97 LBS
              2902-7399-1-SC  D-RING  SC
                                         0.89 Kg
                                        1.97 LBS  14,000 LBS 42,000 LBS  5"  5"  3/4"  3-5/32"  1-3/8"  1-7/8"  3/8"
              2902-7399-1-HDG  D-RING  HDG
                                         0.89 Kg  6,350 Kg  19,050 Kg   127 MM  127 MM  19 MM  80 MM  34 MM  47 MM  9 MM
                                         0.89 LBS
              2902-7399-2-SC  STRAP  SC
                                         0.40 Kg
                                         3.06 LBS
              2902-7593-1-SC  D-RING  SC
                                         1.39 Kg  15,667 LBS 47,000 LBS  5"  5"   1"   2-9/16"  1-11/16" 2-7/32"  7/16"
                                         1.20 LBS  7,106 Kg  21,319 Kg   127 MM  127 MM  25.4 MM 65 MM  43 MM  56 MM 11 MM
              2902-1578-2-SC  STRAP  SC
                                         0.54Kg
                                         3.25 LBS
              2902-1578-1-HDG D-RING  HDG
                                         1.47 Kg
              2902-1578-1-SC  D-RING  SC  3.70 LBS
                                         1.68 Kg  15,667 LBS 47,000 LBS  5"  6"   1"   2-9/16"  1-11/16" 2-7/32"  7/16"
                                         1.20 LBS
              2902-1578-2-HDG  STRAP  HDG  0.54 Kg  7,106 Kg  21,319 Kg  127 MM 152.4 MM 25.4 MM 65 MM  43 MM  56 MM 11 MM
              2902-1578-2-SC  STRAP  SC  1.20 LBS
                                         0.54 Kg
                                           A    C                                      STANDARD-TYPE D-RINGS
                                                                                    NOTE: D-Ring strength for tie-down
                                                                                    purposes only. NOT FOR LIFTING.
                                                 B                           *
              FINISH:                               G     E                        *D-RING SHOWN w/
              SC – SELF-COLOR                                                      2902-7669 BOLT-ON STRAP
              ZP – ZINC-PLATED             D            F
                                                                   D-RING DIMENSIONS      STRAP DIMENSIONS
                  MODEL      DESC.  FINISH WEIGHT  SWL     MBS      A      B      C      D     E     F     G
               2902-7668-1-SC  D-RING  SC  0.64 LBS
                                          0.29 Kg
               2902-7668-1-ZP  D-RING  ZP  0.64 LBS
                                          0.29 Kg
                                                                                 1/2"
                                                                         3-1/2"
                                                                                                          7/32"
                                                                                                    1-1/16"
                                                                                       1-5/8"
                                                                                              7/8"
                                                                  3-1/4"
               2902-7668-2-SC  STRAP  SC  0.25 LBS  3,333 LBS 10,000 LBS  82.5 MM 88.9 MM 12.7 MM 41.2 MM  22.7 MM 27 MM 5.7 MM
                                                 1,511 Kg
                                                         4,536 Kg
                                          0.11 Kg
               2902-7669     STRAP   ZP  0.40 LBS
                                          0.18 Kg
               2902-8477-1-ZP  D-RING  ZP  0.55 LBS
               Military applications      0.25 Kg  4,100 LBS  12,300 LBS              1-25/32"            9/32"
               2902-8477-2-SC  STRAP  SC  0.35 LBS  1,859 Kg  5,579 Kg                 45 MM              7 MM
               Military applications      0.16 Kg
                                                        ®
                                                                    904-696-0010   FAX: 904-696-0019
                                                                                 E-mail: sales@buffersusa.com
                                                          2902-1                                             8/15/18
