Page 12 - lashingcatalogweb
P. 12

®     RATCHET STRAP ASSEMBLIES
                                                             3” X 15’, 3” X 27’ & 3” X 30’



                                                                 3" x 27' WITH FLAT HOOK  MODEL 2905-6068
                                                                 3" x 30' WITH FLAT HOOK  MODEL 2905-6069
                                           3" x 30' WITH FLAT HOOK & SHORT HANDLE  MODEL 2905-6069-SHR
                                    LONG WIDE HANDLE


                                                                            3" STRAP
                              FLAT HOOK


                 SUB 2905-6068 FOR: ANCRA 48987-20, KINEDYNE 552721                               FLAT HOOK
                 SUB 2905-6069 FOR: ANCRA 48987-21, KINEDYNE 553021
                                                                                               COLOR: YELLOW


                                                                 3" x 15' WITH WIRE HOOK  MODEL 2905-6070
                                                                 3" x 30' WITH WIRE HOOK  MODEL 2905-6071

                             LONG WIDE HANDLE


                                                                       3" STRAP

                                 WIRE HOOK
                                                                                          WIRE HOOK

                  SUB 2905-6071 FOR: KINEDYNE 553036
                                                                                               COLOR: YELLOW

                                                             3" x 27' WITH CHAIN ANCHOR  MODEL 2905-6072
                                                             3" x 30' WITH CHAIN ANCHOR  MODEL 2905-6073


                                  LONG WIDE HANDLE

                                                                         3" STRAP
                                                                                       CHAIN ANCHOR
                   CHAIN ANCHOR

                 SUB 2905-6066 FOR: ANCRA 48987-24, KINEDYNE 552740
                 SUB 2905-6067 FOR: ANCRA 48987-25, KINEDYNE 553040
                                                                                               COLOR: YELLOW


              WORKING LOAD LIMIT (WLL): 4,333 LBS / 1,965 Kg
              BREAK STRENGTH (BS): 13,000 LBS / 5,896 Kg
              NOTE:
              FOR LOAD SECURING ONLY,  NOT FOR LIFTING.
              ALL RATCHET STRAP ASSEMBLIES SHOULD BE
              INSPECTED FOR FRAYS, CUTS, OR DAMAGED                       *FIXED LENGTH
              HARDWARE BEFORE AND AFTER USING.                         RATED WORKING LENGTH
              DESIGNED TO MEET OR EXCEED WSTDA T-4 STANDARD.            *FIXED LENGTH 18" EXCEPT
              COMPLIES WITH DOT AND CA HIGHWAY PATROL TITLE 13.          WITH CHAIN ANCHOR 33"


                                                         ®
                                                                   904-696-0010     FAX  904-696-0019
                                                                          E-mail: sales@buffersusa.com
                                                          2905-3
            06/24/15
